Tenda AC10 * V3.0 AC1200 wireless dual band ruter 2.4+5GHz, 1W/3L, Gbit, 1Ghz cpu 128mb,4x6dBi 3299

AC10 offers dual-band Gigabit wireless with all-new 802.11ac Wave 2.0 standard. Its powerful 1GHz CPU provide the best performance in both 2.4GHz and 5GHz. The 5GHz band works at up to 867Mbps, while the 2.4GHz frequency tops 300Mbps, serving an incredible combined bandwidth of 1167Mbps.With 1 GHz CPU made with 28 nm process, AC10 manifests excellent capacity on data processing and energy conservation. It works well with optical fiber with bandwidth ranging from 50 M, 100 M, 200 M to even 1000 M, allowing you to enjoy smooth HD videos and games. Standard&Protocol IEEE802.3, IEEE802.3u, IEEE802.3ab Interface 1*10/100/1000Mbps WAN port 3*10/100/1000Mbps LAN ports Antenna 4*6dBi external antennas Button 1*WPS/Reset button Power Input:AC 100-240V~50/60Hz, 0.4A Output:DC 9V?1A Dimension 8.66 * 5.57 * 1.93 in (220*141.5*49mm)(W*D*H) LED indicator Sys*1,WAN*1, LAN*1,WiFi/WPS*1 Wireless StandardsIEEE 802.11ac wave2/a/n 5GHz IEEE 802.11b/g/n 2.4GHz Data Rate5GHz: Up to 867Mbps 2.4GHz: Up to 300Mbps Frequency Simultaneous dual band 2.4 & 5GHz Transmit PowerCE: <20dBm(2.4G) <23dBm(5G) FCC:<30dBm Basic Features SSID Broadcast: Enable/Disable Transmission Power: high, medium, low Beamforming MU-MIMO Wireless Security WPA-PSK/WPA2-PSK, WPA/WPA2 Wireless Security : Enable /Disable Internet Connection TypePPPoE, Dynamic IP, Static IP Support automatic access detection Supports broadband account automatic transfer Operating ModeWireless Router Mode AP Mode Universal Repeater mode WISP Mode DHCP ServerDHCP Server DHCP Client List DHCP Reservation Virtual ServerPort Forwaring DMZ Host UPnP SecurityClient Filter(supports black list and white list) Parental Control(supports black list and white list) Remote Web Management FirewallForbid UDP flood attack Forbid TCP flood attack Forbid flood attack Forbid WAN PING from internet DDNSSupport DynDNS, 88ip VPNIPsec pass through PPTP pass through L2TP pass through Special Features PPPoE Username/password Clone Smart WiFi Schedule Smart Power Saving Smart LED on/off Tenda Cloud Tenda App Software Other Broadband management MAC address clone Static Routing System Log Backup & Restore configurations Firmware upgrade from local Temperature Operating Temperature: 0? ~ 40? Storage Temperature: -40? ~ 70?. Humidity Operating Humidity:10% ~ 90% RH non-condensing Storage Humidity: 5% ~ 90%RH non-condensing. Default SettingsDefault Access: tendawifi.com or http://192.168.0.1 CertificationCE/FCC/RoHS EIRP Power (Max.)2.400-2.4835GHz: 19.95dBm (EIRP) 5.150-5.250GHz: 22.90dBm (EIRP) Package Content Wireless Router*1 Gigabit Ethernet Cable*1 Power Adapter*1 Installation Guide*1
